Detail Information
| Property | Details | Property | Details |
|---|---|---|---|
| Place Of Origin | CHINA | Brand Name | Linkfuture |
| Certification | CE, SGS, ISO9001 | Model Number | LF |
| Product Name | Colour Paint Protection Film | Heat Resistance | Yes |
| Size | 1.52x15m/60inchx50ft | Scratch Resistance | High |
| Water Resistance | Yes | Healing Type | Self Healing |
| Color | Clear | Adhesive Type | Acrylic |
| MOQ | 1 Roll | Packaging Details | Accept OEM |
| Delivery Time | 5-7 Work Days | Payment Terms | L/C, D/A, D/P, T/T |
| Supply Ability | 100000 Roll/Month | Highlight | 7.5Mil Colour ppf |
Product Description
Paint Protection Film (PPF) – Premium Defense for Luxury & Fleet Vehicles
Bulk Solutions for Wholesalers & OEMs – Scalable, Customizable, Industry-Leading Durability
Meet the demands of discerning automotive partners with Linkfuture, a high-performance Colour paint protection film (PPF) engineered for bulk applications. Designed for wholesalers and brands seeking OEM-grade quality, this film delivers unmatched clarity and 10+ years of UV/chemical resistance, ensuring vehicles retain factory-fresh brilliance across fleets, dealerships, or luxury aftermarket lines.
Wholesale Advantages:
Custom Sizing & Branding: Pre-cut kits for 100+ vehicle models, with optional white-label packaging.
Tiered Pricing: Volume discounts for 50 rolls orders, backed by UPS or FedEx logistics across Wordwide.
Certified Durability: Exceeds ASTM D7869 standards for abrasion resistance (-40°F to 200°F operational range).
Eco-Certified Adhesive: REACH-compliant, residue-free removal for sustainable reapplication.
Ideal for car wrap resellers and automotive brands, Linkfuture combines 7.5-mil thickness with nano-ceramic topcoat technology, reducing post-installation maintenance by 50% compared to standard PPF. Partner with us to elevate your catalog’s premium offering.
Product Structure
Prduct Specifications
| Classification | Unit | Spec | Remark | |
|---|---|---|---|---|
| Thickness | Clearcoat | µm | 50±2% | PET |
| Self-healing Coat | µm | 6.5±2% | / | |
| Face Film | µm | 160±2% | Thermoplastic Polyurethane | |
| Acrylic Adhesive | µm | 25±2% | Solvent based | |
| Release liner | µm | 75±2% | Satin Semi-transparent | |
| Surface | – | Matte Transparent | Super Glossy | |
| Width | mm | 1520±0.01% | 5ft | |
| Length | mm | 15000+1% | 49.21ft | |
| Adhesive appearance | – | Clear | ||
Product Performance
| Features | Test Method | Results |
|---|---|---|
| Release force N/25mm |
paste on steel board, 90° 26℃ and 60%, GB2792 | 0.27 |
| Initial tack N/25mm |
under 26℃ and 64%, GB31125-2014 | 9.5 |
| Peel Adhesion N/25mm |
paste on steel board, 180° 15 Minutes under 29℃ and 55%, GB/T2792-1998 | 9.35 |
| Holding power(h) | paste on steel board, hang on by 25mm*25mm*1kg weight under 29℃ and 55%, GB/T4851-1998 | >75 |
| Gloss(60°) | GB 8807 | ≥90(%) |
| Application temperature | / | +20℃ to +25℃ |
| Service Temperature | / | +20℃ to +80℃ |
| Humidity Resistance | 120 hours exposure | No Detrimental Effect |
| Salt spray Resistance | 120 hours exposure | No Detrimental Effect |
| Water Resistance | 120 hours exposure | No Detrimental Effect |
| Chemical Resistance | 1-hour diesel oil immersion, 4 hours antifreeze immersion | No Detrimental Effect |
| Aging Test 1 | 7 days under 70°C | No adhesive residue with heat |
| Aging Test 2 | 10 days under 90°C | No adhesive residue without heat |
| Elongation at Break | GB/T 1040 | ≥400 |
| Tensile Strength | GB/T 1040 | ≥20 (Mpa) |
| Elongation at Break of Self-healing Coat | GB/T 1040 | ≥85 |
| Application Method | Wet only | / |
| Time Limits | Must use it within 3 Months after you receive the wrap film | 3 Months |
Storage Period
2 Years from the Manufactured Date in Temperature Range of 68 F – 78 F (20 C – 26 C) Relative Humidity 50%, Indoor Storage
Common Applications
- Protection of the highly sensitive external surfaces of the vehicle like; bumper, side mirrors, hood, headlight & wheel arches.
- Protection of internal surfaces like, luggage racks or chairs in busses or trains
- Protection of surfaces in high traffic areas like, reception desks, door impact areas, wall panels and more
- Partial colour change to high gloss black to accentuate specific car parts like roof, mirrors, hood and more
Installation Guidelines
- Clean the vehicle thoroughly.
- Cut PPF sections with extra for trimming.
- Spray soapy water on the surface.
- Apply PPF, float on soapy water.
- Squeegee out air and water, starting from the center.
- Heat and stretch the film to conform.
- Trim excess film with precision.
- Repeat the process for each section.
Please remove the protective cap prior to installation.
Key Information to Note
- Screen Display: Please be aware that the screen’s images, colors, and finishes are approximate. For precise product representation, always refer to the color swatch.
- Consistency in Production: When undertaking a wrapping project, it is advisable to use rolls from the same production LOT number, as there may be slight batch-to-batch variations in color.
- Surface Vulnerability: The film may be susceptible to scratching during application or daily usage. It is important to note that the warranty does not cover any scratching of the film.
How Much Wrap Do I Need?
- Motorcycles: 3-5 meters (10-16 feet)
- Mini and Small Cars: 13-14 meters (42-45 feet)
- Convertibles: 15-16 meters (49-52 feet)
- Coupes: 17-18 meters (55-59 feet)
- Sedans: 17-18 meters (55-59 feet)
- Hatchbacks: 16-17 meters (52-55 feet)
- Sports Cars: 16-17 meters (52-55 feet)
- Station Wagons: 18-20 meters (59-65 feet)
- Sport-Utility Vehicles (SUVs): 17-19 meters (55-63 feet)
- Minivans: 20-24 meters (65-80 feet)
- Pickup Trucks: 22-28 meters (72-92 feet)
To ensure you have sufficient material for potential repairs, it’s advisable to add an extra 2-3 meters (6-9 feet) to your measurements. This precaution will help you avoid unexpected shipping expenses and delays.
To attain a flawless installation, here are some additional tips:
- Maintain a clean and dust-free workspace to prevent imperfections.
- Check for any surface imperfections or damage before starting the installation.
- Use appropriate cutting tools to trim excess material for precise edges and corners.
- Ensure the film is applied smoothly, without wrinkles or bubbles.
- During stretching, be mindful of the film’s limits to avoid overstretching.
- Pay special attention to corners and edges, making sure they are securely adhered.
- For complex curves or contours, use a heat gun or heat source to aid in molding the film.
- Periodically inspect and maintain the installed film to ensure long-lasting quality.
Following these additional guidelines will help you achieve the best possible finish and ensure the longevity of the installed PPF.
FAQ:
FAQ:
Q1: What is the brand name of the color paint protection film?
A1: The brand name of the color paint protection film is Linkfuture.
Q2: What is the model number of the color paint protection film?
A2: The model number of the color paint protection film is LF.
Q3: Where is the color paint protection film manufactured?
A3: The color paint protection film is manufactured in China.
Q4: Does the color paint protection film come with any certifications?
A4: Yes, the color paint protection film comes with CE, SGS, and ISO9001 certifications.
Q5: What is the minimum order quantity for the color paint protection film?
A5: The minimum order quantity for the color paint protection film is 1 roll.
Q6: What are the packaging details for the color paint protection film?
A6: The packaging details for the color paint protection film are customizable and accept OEM.
Q7: What is the delivery time for the color paint protection film?
A7: The delivery time for the color paint protection film is 5-7 work days.
Q8: What are the payment terms for the color paint protection film?
A8: The payment terms for the color paint protection film are L/C, D/A, D/P, T/T, Western Union, and MoneyGram.
Q9: What is the supply ability of the color paint protection film?
A9: The supply ability of the color paint protection film is 80000 roll/month.
